Now featuring Mackie’s flagship Onyx mic preamps, the comprehensive Mackie VLZ4 line delivers the proven feature set, high-headroom/low-noise design and “Built-Like-A-Tank” construction that created an industry more than 25 years ago. From every input to every output, VLZ4 is optimized to deliver professional-quality results each and every time.
1642VLZ4 Features
- 16-channel mixer featuring Mackie signature high-headroom/low-noise design
- 10 boutique-quality Onyx mic preamps
- Ultra-wide 60dB gain range
- 128.5 dB dynamic range
- +22 dBu line input handling
- Extended frequency response
- Distortion under 0.0007% (20Hz – 50kHz)
- Phantom power for studio condenser mics
- Improved RF rejection perfect for broadcast applications
- Phantom power for condenser mics
- 16 high-headroom line inputs with +4/-10 operation control
- 4 aux sends, level, pan and PFL solo on each channel
- 3-band EQ (80Hz, 2.5kHz, 12kHz)
- 18 dB/oct 75Hz low-cut filter on mic input channels
- 60mm long-wearing log-taper faders
- 4 stereo returns for connecting FX processor or other stereo source
- ALT 3/4 stereo bus for added routing flexibility
- Control room / phones source matrix
- High-resolution 12-segment stereo meters
- Sealed rotary control resist dust and grime
- “Built-Like-A-Tank” rugged steel chassis with powder-coat finish
- High-visibility, high-contrast controls deliver convenient “at-a-glance” visual feedback
- Rack-mountable design using optional rack ear kit
- Multi-voltage power supply for worldwide use
1642VLZ4 Physical Properties (packaged product)
- Height: 9.4 in / 239 mm
- Depth: 19.9 in / 505 mm
- Width: 21.3 in / 541 mm
- Weight: 21.0 lb / 9.5 kg
1642VLZ4 Physical Properties (product)
- Height: 16.7 in / 425 mm
- Depth: 5.2 in / 131 mm
- Width: 16.6 in / 421 mm
- Weight: 18.2 lb / 8.3 kg
