Fender Limited Edition Eric Johnson Stratocaster, Maple Fingerboard, Black 0117702806
by Fender
$3,309.99
The Eric Johnson signature Stratocaster® guitar features a light two-piece alder body with deep '57-style body contours and cavities; one-piece, vintage-tinted quartersawn plain maple neck (contours sanded very smooth) with light '57-style "V"-shape, 12" fingerboard radius and highly-polished frets; special Eric Johnson single-coil pickups with countersunk screws and a five-way switch; vintage tremolo with silver-painted block; '57-style string recess; no paint between the base plate and the block; five springs (no tremolo cover); master volume; neck and bridge tone controls; thin neck-cap with staggered machine heads; and '57-style parchment pickguard. Available with .010-.046 gauge strings and thin nitrocellulose lacquer finish.
Model Name
Eric Johnson Stratocaster®, Maple Fingerboard, Black
Model #
0117702806
Series
Artist
Color
Black
Body
Alder
Body Finish
Nitrocellulose Lacquer
Body Shape
Stratocaster®
Neck Material
1-Piece Quartersawn Maple
Neck Finish
Nitrocellulose Lacquer
Neck Shape
Soft "V"
Scale Length
25.5" (648 mm)
Fingerboard
Maple
Fingerboard Radius
12" (305 mm)
Number of Frets
21
Frets Size
Medium Jumbo
String Nut
Bone
Nut Width
1.650" (42 mm)
Position Inlays
Black Dots
Truss Rods
Vintage-Style Butt Adjust
Bridge Pickup
Specially Voiced Eric Johnson Single-Coil with Countersunk Mounting Screws
Middle Pickup
Specially Voiced Eric Johnson Single-Coil with Countersunk Mounting Screws
Neck Pickup
Specially Voiced Eric Johnson Single-Coil with Countersunk Mounting Screws
Controls
Master Volume, Tone 1. (Neck Pickup), Tone 2. (Bridge Pickup)
Pickup Switching
5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup
Pickup Configuration
SSS
Bridge
6-Saddle American Vintage Synchronized Tremolo
Hardware Finish
Nickel/Chrome
Tuning Machines
Vintage-Style Staggered
Pickguard
1-Ply Parchment
Control Knobs
Parchment Plastic
Strings
Fender® USA 250R, NPS, (.010-.046 Gauges)
Unique Features
12" Radius Fingerboard, Countersunk Holes in Pickguard for Pickup Mounting Screws, Height Staggered Vintage Style Tuners which Eliminate the Need for String Trees, Vintage Tremolo with Silver Painted Block and '57 Style String Recess (No Paint Between Base Plate and Block), 5 Tremolo Springs and No Back Tremolo Cover Plate
Included Accessories
Deluxe Blonde Hardshell Case with Black Ends (Black Interior), Strap, Cable, "Ash Tray" Bridge Cover
